52
9.3.3.8. Putting Sheets
(Attention)
Affixation load of affixation thing not instructed : More than
Connector externals application
Management size : 0-1m
Connector externals application
Management size : 0-1mm
Grease(G-751)
Pressurize
More than 1-1.5
Execute after setting the substrate in the receiving treatment
device when working.
Connection
Heat Spreader Bottom
Connector direction
change
3mm
3mm
5mm
From the coil
externals
1mm
PET Tape PET Tape
Processes in the dotted line
SW Cable Sheet
Between cushion and addable
memory Processing
Processes between the
connector and the coil
Between cushion and coil
Processing
HEAT SHEET Cushion
The HEAT cushion is affixed in the place without the chip wireless LAN
connector sideward.
Do not run aground in the chip on side.
It is unquestionable for the inclination as long as does not run aground.
