37
A Flexible cable connector right edge of the control substrate is matched to the inverter connector left end.
TP Flexible cable is bent once
and the line is processed.
Does not hang to the connector on LCD.
Two sided tape pressurizing
1mm or more
TP TAPE
The edge is matched
and the substrate is affixed.
TS substrate
The upper part of the LCD resin frame is matched.
9.3.2.10. Putting PET Tape
A red line of the cable is matched
to the LCD frame externals
