C 1112
C 1113
C 1110
F1G1E223A062
CAPACITOR, 25V, 0.022µF
1
C 1101
F1G1E472A062
CAPACITOR, 25V, 4700pF
4
C 1102
C 1103
C 1104
C 1111
F1G1H102A450
CAPACITOR, 50V, 1000pF
1
C 1114
F1G0J224A001
CAPACITOR, 6.3V, 0.22µF
1
C 1115
F1J0J475A009
CAPACITOR, 6.3V, 4.7µF
1
C 1116
F1J0J106A024
CAPACITOR, 6.3V, 10µF
1
CN 1101
K1KA05BA0014
CONNECTOR
1
CN 1102
K1MN04B00078
CONNECTOR
1
IC 1101
C0EBE0000460
IC
1
IC 1102
C1CB00002515
IC, TOUCHPANEL CONTROLLER
1
IC 1103
C0CBCAC00312
IC, REGULATOR
1
Q 1101
XP0431400L
TRANSISTOR
2
Q 1102
Q 1103
UNR9113J0L
TRANSISTOR
1
Q 1104
UNR9213J0L
TRANSISTOR
1
R 1101
ERJ2GEJ473X
RESISTOR, 1/16W, 47KΩ
2
R 1107
R 1104
ERJ2GEJ102X
RESISTOR, 1/16W, 1KΩ
12
R 1106
R 1110
R 1111
R 1112
R 1113
R 1118
R 1120
R 1121
R 1122
R 1123
R 1130
R 1114
ERJ2GEJ822X
RESISTOR, 1/16W, 8.2KΩ
4
R 1115
R 1116
R 1117
R 1124
DEARA8AJ473M
RESISTOR ARRAY
1
R 1125
ERJ2GEJ270X
RESISTOR, 1/16W, 27Ω
2
R 1126
R
1127
ERJ2GEJ152X
RESISTOR, 1/16W, 1.5KΩ
1
R 1129
ERJ2GE0R00X
RESISTOR, 1/16W, 0Ω
1
R 1109
ERJ2GEJ273X
RESISTOR, 1/16W, 27KΩ
1
R 1119
ERJ2GEJ512X
RESISTOR, 1/16W, 5.1KΩ
1
X 1101
H2D600400005
OSCILLATOR, 6MHz
1
WWAN PCB
C 1501
F1J0J106A016
CAPACITOR, 6.3V, 10µF
3
C 1523
C 1527
C 1502
F1G1C104A042
CAPACITOR, 16V, 0.1µF
5
C 1503
C 1504
C 1516
C 1528
C 1505
F1G1H101A451
CAPACITOR, 50V, 100pF
1
C 1520
F1G1H221A495
CAPACITOR, 50V, 220pF
1
C 1524
EEFCX0G151R
CAPACITOR, 2V, 150µF
2
C 1525
CN 1501
K1KA12BA0014
CONNECTOR
1
