Grizzly G0632 User Manual
Page 8
-6-
G0632 16" x 42" Variable Speed Wood Lathe
Figure 2. Model G0632 headstock.
A. Motor
B. Motor Wiring Junction Box
C. Spindle Handwheel
D. Spindle Handwheel Safety Cover
E. Frequency Inverter
F. Spindle Lock
G. Front Belt Access Panel
H. Control Panel
I. Indexing Pin Holes
J. Face Plate
K. Headstock Rotation Lock
L. Motor Tensioning Handle
M. Motor Mount Cap Screw
A
B
C
D
E
F
G
H
J
L
K
I
M
