Grizzly G0632 - Manual (Page 49)

G0632 16" x 42" Variable Speed Wood Lathe
-47-
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
31 P0632031 SPUR CENTER 63 PK33M KEY 5 X 5 X 45
32 PSS64M SET SCREW M6-1 X 15 64 P0632064 MOTOR PULLEY
33 P0632033 FACE PLATE 65 PSS64M SET SCREW M6-1 X 15
34 P0632034 SPINDLE 66 PSB64M CAP SCREW M10-1.5 X 25
35 PK12M KEY 5 X 5 X 30 67 PSB64M CAP SCREW M10-1.5 X 25
36 P6207 BALL BEARING 6207ZZ 68 PW04M FLAT WASHER 10MM
37 P6206 BALL BEARING 6206ZZ 69 P0632069 MOTOR MOUNTING PLATE
38 PR38M INT RETAINING RING 62MM 70 P0632070 FEMALE KNOB M8-1.25
39 PR15M EXT RETAINING RING 30MM 71 PN29M HEX NUT M18-2.5
40 P0632040 INDEX PIN 72 P0632072 CLAMP
41 P0632041 HEADSTOCK 73 P0632073 HEADSTOCK LOCK BRACKET
42 P0632042 HEADSTOCK WIRING HARNESS 74 P0632074 BUSHING
43 PR07M EXT RETAINING RING 18MM 75 PR17M EXT RETAINING RING 26MM
44 P0632044 HEADSTOCK LOCK HANDLE 76 P0632076 ROTATION BRACKET
45 P0632045 BRAKING RESISTOR 77 P0632077 ROTATION LOCK PIN
46 PHTEK12M TAP SCREW M5 X 15 78 P0632078 COMPRESSION SPRING
47 PSB33M CAP SCREW M5-.8 X 12 79 P0632079 SPINDLE LOCK PIN
48 P0632048 FREQUENCY INVERTER 80 P0632080 PLATE
48-1 P0632048-1 FREQ INV SAFETY COVER 81 P0632081 BRACKET
49 P0632049 WIRING BRACKET 82 PSB10M CAP SCREW M5-.8 X 15
50 P0632050 POWER CORD 83 PS08M PHLP HD SCR M5-.8 X 12
51 P0632051 MOTOR WIRING HARNESS 84 P0632084 FRONT BELT ACCESS PANEL
52 PS55M PHLP HD SCR M3-.5 X 10 85 P0632085 VARIABLE SPEED KNOB
53 P0632053 STRAIN RELIEF 86 P0632086 VARIABLE SPEED CONTROL
54 P0632054 RIBBED BELT 180J6 87 P0632087 FWD/REV SWITCH
55 PSS80M SET SCREW M8-1.25 X 15 88 P0632088 EMERGENCY STOP SWITCH
56 P0632056 SPINDLE PULLEY 90 P0632090 FLAT HD SCR M3-.5 X 30
57 PS08M PHLP HD SCREW M5-0.8 X 12 91 P0632091 RPM READOUT CIRCUIT BOARD
58 P0632058 SIDE BELT ACCESS PANEL 92 P0632092 RPM READOUT LED
59 P0632059 SPINDLE HANDLE 93 P0632093 RPM SENSOR
59-1 P0632059-1 HEX BOLT M8-1.25 X 140 94 PN07M HEX NUT M3-.5
59-2 PN03M HEX NUT M8-1.25 95 PS50M PHLP HD SCR M3-.5 X 12
59-3 P0632059-3 RUBBER WASHER 8MM 96 P0632096 FLAT HD SCR M3-.5 X 20
59-4 P0632059-4 SPINDLE HANDLE SAFETY COVER 97 P0632097 CONTROL PLATE
60 P0632060 KNOCKOUT TOOL 98 PR07M EXT RETAINING RING 18MM
61 P0632061 MOTOR 220V,3-PHASE 101 P0632101 ALL THREAD M3-.5 X 25
61-1 PS49M PHLP HD SCR M3-.5 X 5 102 PN07M HEX NUT M3-.5
61-2 PLW09M LOCK WASHER 3MM 103 PS09M PHLP HD SCR M5-.8 X 10
61-3 PW07M FLAT WASHER 3MM 104 P0632104 DIVIDING PLATE
61-4 P0632061-4 FAN COVER 105 P0632105 COMPRESSION SPRING
61-5 P0632061-5 FAN 106 P0632106 SPECIAL NUT
61-6 P0632061-6 MOTOR JUNCTION BOX 107 P0632107 COMPRESSION SPRING
61-7 P0632061-7 JUNCTION BLOCK 108 PR39M EXT RETAINING RING 8MM
62 PSS64M SET SCREW M6-1 X 15 109 PSS31M SET SCREW M5-.8 X 8
