Magnum 3000 Stackable Hubs Installation and User Guide (07/06)

2

www GarrettCom com

.

.

DC Power Supply (Options)

-48VDC Power Input Voltage : 36 to 72 VDC
24VDC Power Input Voltage : 20 to 36VDC
125VDC Power Input Voltage : 120 to 300VDC
Std. Terminal Block : “ -, GND, + ”

Power Consumption: same as for AC models, see above

For Dual Source and Redundant DC for –48VDC, 24VDC Power &
125VDC supply options (Optional), see Appendices.

Packaging

Enclosures: High strength sheet metal, suitable for wiring closet

shelf, rack or table-top mounting.

Dimensions: Models 3024, 3012, 3000-AGT: 9.0 in x 17.0 in x 1.75 in

(22.9 cm x 43.2 cm x 4.45 cm)

Weight: Model 3024: 5.0 lbs (2.3 Kg), Model 3012 and

3000-AGT:4.0 lbs (1.8 Kg)

Cooling method: Models 3024, 3012, 3000-AGT: Convection except

3012 and 3024 w/ embedded agent: Fan cooled, internal @ 7cfm

LED Indicators on Chassis Front

PWR - Power, Green LED, steady on when AC power is applied.

LINK - (Models 3024 & 3012) Per RJ-45 port, Steady On when twisted

pair link is operational, flashing if the port is partitioned by hardware

RX - (Models 3024 and 3012) Per RJ-45 port, Receive, Green LED,

blinks to indicate activity of data being received on the port.

Agency

Approvals

UL Listed (UL 1950), cUL, CE

Emissions: meets FCC Part 15 Class A

Optional: ETSI and NEBS L3 Certified

Warranty

Three years, return to factory

Made in USA
