Magnum 3000 Stackable Hubs Installation and User Guide (07/06)
iii
www GarrettCom com . .
PREFACE
This user guide is divided into six main sections:
SECTION 1 covers the product specifications for Magnum 3000 Stackable
Hubs family, and also provides ordering information.
SECTION 2 covers the Magnum 3024 and 3012 Stackable Hubs.
SECTION 3 d escribes Magnum Repeater Port Modules (RPMs) and Bridge
Port Modules (BPMs) including features, installation and operation.
SECTION 4 describes management options for the Magnum 3000 family;
the SNMP agents, how they are installed and used.
SECTION 5 discusses troubleshooting and warranty procedures for all
of the Magnum 3000 Stackable Hubs .
REVISIONS
R07/06: Updated Rack-mounting and Appendix B & C with 24VDC and 125VDC
Power Supply Option as per UL instructions.
R05/02: Updated Rack-mounting and Appendix B & C with 24VDC and 125VDC
Power Supply Option
R01/02: Updated Operating Environment Specifications
R07/01: -48VDC (OPTIONAL) and Fuse info. added in Specifications
R03/01 : Change the company’s name to GarrettCom, Inc.(formerly it was Garrett
Communications). There are no changes made to the content material at this time.
R3/99 : This revision revises the appendices covering 48V power options.
R10/98: This revision separates the Magnum 3000 hubs manual from the 3000X
Concentrator manual, and revises the appendices covering 48V power options.
R9/97: This revision includes a safety precaution at the beginning of both Installation
sections for the 3012 / 3024, and the RPM-FSC
R3/97: This revision includes a new Appendix A: the 48VDC power option; the
previous Appendix A: Warranty Information is now labeled as Appendix B.
R1/96:The following revisions have been made to the Magnum 3000 product line
and Users’ Guide since the (02/95) release: An IRB Segmenting Cable has been
developed (see Section 2.3.2) which allows 3000s to be physically stacked together
and controlled by a single SNMP agent, while remaining isolated from each other;
The distance jumpers on the Magnum RPM-FST and RPM-FSM have been
documented (see Sections 3.2.4 and 3.2.5); Installation of PMs for the 3012 and 3024
Bonus Ports is now documented (see Section 2.5).
