Magnum 3000 Stackable Hubs Installation and User Guide (07/06)
35
www GarrettCom com . .
Table 5.1.3: Magnum SNMP Agent Commands
Variable Type
Repeater ID ATTRIBUTE GET
Repeater Group Capacity ATTRIBUTE GET
Group Map ATTRIBUTE GET
Repeater Health State ATTRIBUTE GET
Repeater Health Text ATTRIBUTE GET
Repeater Health Data ATTRIBUTE GET
Transmit Collisions ATTRIBUTE GET
Reset Repeater ACTION
Execute Non disruptive self Test ACTION
Repeater Health NOTIFICATION
Repeater Reset NOTIFICATION
Group Map Change NOTIFICATION
Resource Type ID Name ATTRIBUTE GET
Resource Info. ATTRIBUTE GET
Group ID ATTRIBUTE GET
Group Port Capacity ATTRIBUTE GET
Port Map ATTRIBUTE GET
Port Map Change NOTIFICATION
Port ID ATTRIBUTE GET
Port Admin. State ATTRIBUTE GET
Auto Partition State ATTRIBUTE GET
Collisions ATTRIBUTE GET
Readable Frames ATTRIBUTE GET
+
Readable Octets ATTRIBUTE GET
+
Frame Check Sequence Error ATTRIBUTE GET
+
Alignment Error ATTRIBUTE GET
+
Frame Too Long ATTRIBUTE GET
+
Short Events ATTRIBUTE GET
+
Runts ATTRIBUTE GET
+
Late Events ATTRIBUTE GET
+
Very Long Events ATTRIBUTE GET
+
Data Rate Mismatches ATTRIBUTE GET
+
Last Source Address ATTRIBUTE GET
+
Source Address Changes ATTRIBUTE GET
+
Auto Partitions ATTRIBUTE GET
Port Admin. Control ACTION
note: “
+
” indicates a statistic added via MIB extension
