Magnum 8000X Mixed-Media Fiber Hubs Installation and User Guide (05/ 02)
53
www GarrettCom com
.
.
B5.0
OPERATION
Operation of the Magnum 8000X with the optional -48VDC, 24VDC &
125VDC power supply is identical to that of the AC-powered models.
B6.0
ORDERING INFORMATION
To order the optional –48VDC power supply factory installed, add a suffix of
“-48VDC” after the product’s standard model # Example: Magnum 8000X-48VDC.
Similarly, to order the optional 24VDC or 125VDC industrial specific power
supply factory installed, add a suffix of “–24VDC or “–125VDC” after the product’s
standard model #. Example: Magnum 8000X-24VDC or Magnum 8000X-125VDC.
B7.0
TROUBLESHOOTING Please refer to Section 6.0
APPENDIX C: Internal DC Dual-Source Power Option
C1.0
SPECIFICATIONS - FOR 8000X MIXED-MEDIA FIBER HUBS
Power Supply (Internal, -48VDC Dual-Source, model # Dual-Src48V)
DC Power Connector: First Source: “A+”, “A
-“
, 2nd Source “B
-
“, “B+”
GND: Terminal for “earth” or ground wire connection to the hub chassis
Input: Two separate sources, each at 36 - 70 VDC
Power Consumption: Model 8000X: 30 watt typical, 50 watts max.
Power Supply (Internal, 24VDC Dual-Source, model # Dual-Src24V)
DC Power Connector: First Source: “A+”, “A
-“
, 2nd Source “B
-
“, “B+”
GND: Terminal for “earth” or ground wire connection to the hub chassis
Input: Two separate sources, each at 20 - 36 VDC
Power Consumption: Model 8000X: 30 watt typical, 50 watts max.
Power Supply (Internal, 125VDC Dual-Source, model # Dual-Src125V)
DC Power Connector: First Source: “A+”, “A
-“
, 2nd Source “B
-
“, “B+”
GND: Terminal for “earth” or ground wire connection to the hub chassis
Input: Two separate sources, each at 120 - 160 VDC
Power Consumption: Model 8000X: 30 watt typical, 50 watts max.
With the exception of the dual DC input power connections and the power
supply, all specifications and configuration options for the Magnum 8000X-48VDC,
8000X-24VDC & 8000X-125VDC with this Dual-Source option are identical to those
listed in the Magnum 8000X Fiber Hubs Installation and User Guide, including
Appendix B “Internal DC Power Supply Option”
C2.0
MAGNUM 8000X , with -48VDC, 24VDC & 125VDC Dual-Source option
