Magnum 8000X Mixed-Media Fiber Hubs Installation and User Guide (05/ 02)
3
www GarrettCom com
.
.
1.1 Specifications - Port Modules, for front ports of the Magnum 8000X
(For Power Budget data, see Section 4.5)
PM Model #
IEEE Standard Speed
Connector type
-Mode
FPM-MST
FX
100Mbps
ST “twist-lock”
multi-
FPM-MSC
FX
100Mbps
SC “snap-in”
multi-
FPM-SSC
FX
100Mbps
SC “snap-in”
single-
FPM-MTRJ
FX
100Mbps
MT-RJ “plug-in”
multi-
FPM-MV45
FX
100Mbps VF-45 “plug-in”
multi-
FPM-SXMST
SX
100Mbps
ST “twist-lock”
multi-
FPM-SXMSC
SX
100Mbps
SC “snap-in”
multi-
FPM10-MST
FL
10Mbps
ST “twist-lock”
multi-
FPM10-MSC
FL
10Mbps
SC “snap-in”
multi-
FPM10-SST
FL
10Mbps
ST “twist-lock”
single-
FPM10-SSC
FL
10Mbps
SC “snap-in”
single-
FPM-MFC
FL
10Mbps
FC “screw-on”
multi-
PM-RJ45
-T, TX 10/100 auto-neg.
RJ-45
twisted pair
PM-RJ45U
-T, TX 10/100 auto-neg. RJ-45 with up-link sw. TP
PM-BLNK
Blank cover for an unused port slot
Two LED indicators per fiber port, in each PM, are “L” for LINK is made, “A” for traffic Activity.
Additional LED for RJ-45 ports are “S” for Speed, where flashing indicates auto-negotiation is
ready (or nothing is connected), steady ON indicates 100Mbps operation and OFF means
10 Mbps
operation has been selected by the last auto-negotiation session.
1.2 Specifications - Switching Port Modules (SPMs) for bonus port
* PDV (path delay value) of an SPM is the same as a user-node i.e. , 50 BT
SPM Type *
SPM-TTX
SPM-FDSC
SPM-FDST
SPM-FDSSC
Physical Signaling Type 100BASE-TX
& 10BASE-T
100BASE-FX
mm* f. duplex
100BASE-FX
mm* f. duplex
100BASE-FX
sgl.mode, fdx
Connector Type
RJ-45
Fiber-SC
Fiber-ST
Fiber-SC
LINK LED
yes
yes
yes
yes
Receive (RX) LED
yes
yes
yes
yes
Up-link switch
yes
n.a.
n.a
n.a.
10/100Mb switch
yes
n.a.
n.a.
n.a.
(For power budget data, see Section 4.5)
