Graco Inc. 244581 User Manual
Instructions/parts list, Wb100 isolation system and pro, Xs3 spray gun

WB 100
Isolation Enclosure
PRO Xs3
Smart Gun and
Fluid Hose
TI2139a
TI1681A
309293K
Instructions/Parts List
ELECTROSTATIC, WATERBORNE, AIR SPRAY
WB100 Isolation System and PRO
™
Xs3 Spray Gun
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
For use when electrostatically spraying conductive,
waterborne fluids that meet at least one of the
following conditions for non-flammability:
FM Approved
•
The fluid has a flash point above 140
°
F (60
°
C)
and a maximum organic solvent concentration of
20%, by weight, per ASTM Standard D93. FM
•
The fluid does not sustain burning when tested per
ASTM Standard D4206 Sustained Burn Test.
CE-EN 50059 Compliant
•
Materials which cannot be ignited, in any mixture
with air, by an energy source of less than 500 mJ.
See page 3 for a List of Models
U.S. Patent No. 7,226,004
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Document Outline
- List of Models
- Symbols
- Warning
- Warning
- Introduction
- Installation
- Operation
- Maintenance
- Electrical Tests
- Troubleshooting
- Repair
- Prepare the Gun for Service
- Air Cap/Nozzle Replacement
- Electrode Replacement
- Fluid Packing Removal
- Packing Rod Repair
- Barrel Removal
- Barrel Installation
- Power Supply Removal and Replacement
- Turbine Alternator Removal and Replacement
- Fan Air Adjustment Valve Repair
- Fluid Adjustment Valve Repair
- Air Valve Repair
- Atomizing Air Restrictor Valve Removal and Replacement
- ES ON/OFF Valve Repair
- Parts
- Accessories
- Technical Data
- Graco Standard Warranty
- Graco Information
