4-28
Using Set-Up Mode
baud rate as that used by your computer or modem.
600 BPS
1200 BPS
2400 BPS
4800 BPS
9600 BPS
19200 BPS
Setting of data format for DEC-423
Number of data bits
Parity bit
7 EVEN
7
Even
7 ODD
7
Odd
7 SPACE
7
Space *
7 MARK
7
Mark *
8 EVEN
8
Even
8 ODD
8
Odd
8 NONE
8
None
* The mark is logical 1. The space is logical 0.
Setting of data transmission buffer control for DEC-
423
DTR
The Data Terminal Ready signal is used.
X O N / X O F
The DC1 and DC3 codes are used.
Specify the disconnect control of the interface when a
fault condition occurs.
NO
DTR is kept as it was.
DROP DTR
DTR is turned low and fixed.
PULSE DTR
DTR is turned low for five seconds and returned to
the original state.
(Buffer Control)
(Disconnect on
Fault)
