2-12
Paper Handling
Note:
Below the left paper guide
1
11
11, the cut sheet stand has a scale graduated in units
of 0.1 inch. When the left paper guide is positioned all the way to the right, the
left margin is 5 mm (0.2 inch). To help align paper, also use the inch-based ruler
on the top cover
2
22
22 of the printer. The gradations on the ruler are for 10 columns
per inch.
Setting Paper Select Lever and Left Paper Guide
5. Adjust the right paper guide
3
33
33 to the width of paper. Insert the paper into the cut sheet
stand. Make sure that the bottom edge of the paper engages snugly with the platen. The
paper will automatically advance to the top-of-form position if the Single Sheet Load
option of the Set-Up mode is set to Automatic.
Note:
The factory setting for the Single Sheet Load option is automatic loading, two
seconds after paper detection. If you set this option to manual, you will have to
press
FF/Load
to feed the paper.
2
22
22
1
11
11
