Paper Handling
Overview of Paper Operations
The following levers and buttons are used in paper handling:
•
Paper select lever
1
11
11 at the top left corner of the printer
•
Paper thickness lever
2
22
22 at the top right corner of the printer
•
All buttons
6
6
6
6
6 on the control panel 3
33
33 (Primary and alternative functions are labelled
respectively above and under each button.)
The following figure shows the location of each lever, indicators, and buttons:
Paper select lever
1
11
11
Font indicators
4
44
44
Paper thickness lever
2
22
22
Macro indicators
5
55
55
Control panel
3
3
3
3
3
Buttons
6
66
66
Printer Levers and Buttons
The following table summarizes the use of levers and buttons in paper handling. More
detailed information is provided later in this chapter.
Caution:
To load or feed paper, the printer must be:
• In the Ready state but not receiving or printing data
• In the Pause state
