Component Identification
3A0157A
7
Component Identification
11.
12.
10.
13.
1.
2.
4.
5.
6.
7.
8.
9.
3.
ti14839a
1
Premium Digital Display
2
ON/OFF switch
3
WatchDog
™
Switch (not available on Mark V)
4
Pressure Control
5
Prime / Spray Valve
6
Filter
7
Siphon Tube
8
Pump
9
Bearing Housing / ProConnect
™
10
Drain Tube
11
Trigger Lock
12
Model/serial tag
13
Hose Reel
