G8692 Portable Bandsaw and Stand -25-
Design Type .................................................................................................. Bench Model
Overall Dimensions:
Table ..............................................................................................................7 1 ⁄
8
" x 5 1 ⁄
2
"
Overall Height ..........................................................................................................14"
Overall Width ............................................................................................................13"
Overall Depth including Fence ..............................................................................18
1 ⁄
2
"
Shipping Weight ..................................................................................................31 lbs.
Box Size ..................................................................................12" W x 23" L x 14
1 ⁄
2
" H
Footprint ......................................................................................................10" x 18 1 ⁄
2
"
Cutting Capacity:
Left of Blade ..........................................................4 3 ⁄
4
" Round, 4 1 ⁄
2
" x 4 3 ⁄
4
" Rectangular
Cutting Angle ............................................................................................................90˚
Construction:
Table ..........................................................................................................Sheet Metal
Wheels ..................................................................................Rubber Coated Aluminum
Vise ............................................................................................................Sheet Metal
Wheel Covers..............................................................................................Sheet Metal
Guides ........................................................................................................Ball Bearing
Main Body ......................................................................................Aluminum & Plastic
Motor:
Type ............................................................................................Universal Brush Type
Horsepower ............................................................................................................1 HP
Bearings..........................................................Shielded & Permanently Lubricated Ball
Phase ⁄ Cycle................................................................................Single Phase ⁄ 60 HZ
Voltage ..................................................................................................................110V
Amps ....................................................................................2 Amps low, 3 Amps high
Switch ........................................................................................ Button Switch w/ Lock
Blades :
Blade Width................................................................................................................ 1 ⁄
2
"
Blade Speed..........................................................................................190 & 262 FPM
Standard Blade Length ..........................................................................................44
7 ⁄
8
"
Features:
..................................................................................Includes: Stand with locking vise
............................................................................................................Double Insulated
Specifications, while deemed accurate, are not guaranteed.
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G8692 PORTABLE BANDSAW
MACHINE DATA
SHEET
