Grizzly G8692 User Manual
Page 10
G8692 Portable Bandsaw and Stand
-9-
1.
Motor Brush Housing
2.
Work Stand Mounting Brace
3.
Blade Tension Lever
4.
Locking Chain
5.
Vise
6.
Quick Nut
7.
Hand Crank
8.
Blade
9.
Hi/Low Speed Switch
10.
Power Cord
11.
Safety button
12
. Trigger
Figure 1.
Main view of machine features and controls.
SECTION 4: MACHINE FEATURES
10
11
12
1
3
2
4
5
6
7
8
9
