308-425

11

Operation

06225

F

A

B

D

103

4

102

8

7

G

H

Detail of Air Line Connection

and Air Regulation Kit (19)

Fig. 3

Model 237–296 Shown

KEY
4 Fluid Filter (includes drain valve D)

(surge tank on Model 237–281)

D Fluid Drain Valve (required)

7 Suction Tube

8 Suction Hose

102Airless Spray Gun

103Electrically Conductive Fluid Supply Hose

A Main Air Line

B Bleed-Type Master Air Valve (for accessories)

F Red-Handled Bleed-Type Master

Air Valve (required, for pump)

G Air Line Inlet Swivel

H Pump Air Filter/Regulator

K Packing Nut/Wet-Cup

1

Torque to 100–110 ft-lb (136–149 N.m)

K

1

F
