307912 39
Technical Data
Category Data
Gun Weight 1.87 lb (0.85 Kg)
Gun Length 9.5 in. (240 mm)
Maximum Working
Pressure 100 psi (7 bar, 0.7 MPa)
Air Pressure
Operating Range 0–100 psi (0–7 bar,
0–0.7 MPa)
Fluid Pressure
Operating Range 0–100 psi (0–7 bar,
0–0.7 MPa)
Voltage Output 0–65 kV
Paint Resistivity
Range 7 megohm-cm to infinity
Air Inlet 1/4 npsm(m) left-hand
Fluid Inlet 3/8 npsm(m)
Typical Noise Level
at 40 psi (2.8 bar,
0.28 MPa)* Sound Pressure { 87 Db(A)
Sound Power
}
90.4 Db(A)
Maximum Noise
Level at 100 psi
(7 bar, 0.7 MPa)** Sound Pressure
{
99 Db(A)
Sound Power } 105.4 Db(A)
Category Data
Wetted Parts Stainless Steel, Polyethylene,
Nylon, Acetal, PTFE, Ultra
r
High Molecular Weight
Polyethylene, Ceramic,
Fluoroelastomer, Music Wire
* Noise levels measured with a 40 psi (2.8 bar) air supply at
the gun air inlet and typical gun air flow settings.
** Noise levels measured with a 100 psi (7 bar) air supply at
the gun air inlet and maximum gun air flow settings.
{ Sound pressure was measured per Cagi Pneurop, 1969.
} Sound power was measured per ISO–3744, 1981.
Kalrez r and Viton r r are registered trademarks of the
DuPont Co.
Loctite r is a registered trademark of the Loctite Corporation.
Chemraz r is a registered trademark of the Green, Tweed
and Company.
Manual Change Summary
This manual has been changed per ECO’s V6099, V5645, and V5457.
