307912 37
Accessories
Use Only Genuine Graco Parts and Accessories
FLUID LINE ACCESSORIES
Fluid Hose Assemblies (Nylon)
225 psi (14 bar, 1.4 MPa) Maximum Working Pressure
FM Approved; 1/4 in. (6.35 mm) ID, 3/8 npsm(fbe)
215637 25 ft (8 m)
215638 50 ft (15 m)
Fluid Hose Assemblies (Nylon)
500 psi (35 bar, 3.5 MPa) Maximum Working Pressure
FM Approved; 1/4 in. (6.35 mm) ID, 3/8 npsm(fbe)
216076 25 ft (8 m)
216077 50 ft (15 m)
216079 100 ft (30 m)
Fluid Tube (PTFE) 185806
100 psi (7 bar, 0.7 MPa) Maximum Working Pressure
For reducing flushing time. Replaces item 12 in parts
list. 0.078 in. (1.98 mm) ID, 0.375 in. (9.53 mm) OD,
5.50 in. (139 mm) long
Fluid Shutoff/Drain Valve
500 psi (35 bar, 3.5 MPa) Maximum Working Pressure
For turning fluid off or on to the gun and for relieving
fluid line pressure at the pump
208630 1/2 npt(m) x 3/8 npt(f); carbon steel and
PTFE; for non-corrosive fluids
SPRAY SYSTEM ACCESSORIES
Electrostatic System 223106
Includes:
222300 Electrostatic Air Spray Gun
223070 Grounded Air Hose; 25 ft (8 m)
216076 Fluid Hose; 25 ft (8 m)
106148 Air Filter
Electrostatic System 223027
Includes:
222300 Electrostatic Air Spray Gun
223070 Grounded Air Hose; 25 ft (8 m)
206199 Air Regulator with Gauge
106149 Air Filter
158491 Nipple
158212 Bushing
164672 Adapter
Electrostatic System 223028
Includes:
222300 Electrostatic Air Spray Gun
223071 Grounded Air Hose; 36 ft (11 m)
206199 Air Regulator with Gauge
106149 Air Filter
158491 Nipple
158212 Bushing
164672 Adapter
Electrostatic System 223029
Includes:
222300 Electrostatic Air Spray Gun
223072 Grounded Air Hose; 50 ft (15 m)
206199 Air Regulator with Gauge
106149 Air Filter
158491 Nipple
158212 Bushing
164672 Adapter
Continued on page 38.
