307912 35
Parts
WARNING
Some PRO 3500sc Gun replacement parts look similar to
other PRO Gun parts but are not interchangeable! When
servicing, do not mix or use other PRO Gun parts!
Use of parts other than those specified in the parts list
below could alter the grounding continuity of the gun,
cause parts to leak or rupture, or cause the gun to
malfunction and result in serious injury, fire, explosion or
property damage.
Part No. 222300 , Series B
Electrostatic Air Spray Gun, with two-finger trigger
Part No. 222600 Electrostatic Air Spray Gun
Electrostatic Air Spray Gun, with four-finger trigger
Ref
No.
Part No. Description Qty
1 193033 AIR CAP; See Manual 307803 for
available air caps
1
2 176930 RING, retaining 1
3 222314 BARREL, gun 1
4 185095 SCREW, trigger 2
5 185096 SCREW, cap, relieved; M5 x 0.8 3
6 185097 HOOK 1
7 222666 HANDLE, gun 1
8 187423 NUT, air cap 1
9* 110077 FERRULES, fluid tube 1
10 110078 FITTING, fluid tube 1
11
Y}
179791 TAG, warning 1
12 185100 TUBE, fluid 1
13 191904 TRIGGER, 2 finger;
Model 222300 only
1
191905
}
TRIGGER, 4 finger
Model 222600 only
1
14 110079 NUT, fluid tube 1
15 185122 MUFFLER (flame arrestor) 1
16 185104 BRACKET, 2 finger;
Model 222300 only
1
236120 BRACKET, 4 finger;
Model 222600 only
1
17 185105 FITTING, air 1
18 222333 POWER CARTRIDGE, 65 kV
Includes items 18a–18f
1
18a { 185134 S GASKET, power supply 1
18b { 106555 S O-RING, Viton r 1
18c 110098 S SPRING, compression 1
18d 185141
S
CUSHION, power supply 1
18e 185099 S PAD 1
18f 185145 S PAD 1
19 { 106555 O-RING; Viton 2
20 190933 NEEDLE, electrode 1
21 185158 NOZZLE, fluid, See Manual 307803
for available nozzles
1
22 223977 STUD, resistor 1
23 109450 O-RING, PTFE r 1
24 110083 SET SCREW, lever; M4 x 0.7 1
25* 111507 O-RING; fluoroelastomer 1
26 186839 LEVER, ES valve 1
28 223444 FLUID PACKING & NEEDLE ASSY.
Includes items 28a–28h
1
28a 223024 S NEEDLE, fluid 1
28b 185495 S HOUSING, packing 1
Ref
No.
Part No. Description Qty
28c 185488 S NUT, packing 1
28d* 178763 S PACKING, needle 1
28e* 178409 S PACKING, fluid 1
28f* 111504 S O-RING, fluoroelastomer 1
28g* 111316 S O-RING, fluoroelastomer 1
28h* 186069 S SPACER 1
29* 185120 SEAL, fluid 1
30 185111 SPRING, compression 1
31 238927 VALVE, atomizing air 1
32 185119 SPACER, lever 1
33 185112 ADAPTER, exhaust hose;
Model 222300 only
1
188878 ADAPTER, exhaust hose;
Model 222600 only
1
34 { 185113 GASKET, manifold; polyethylene 1
35 185114 RING, retainer, alternator 1
36 113746 O-RING, CV75 1
37 222319 ALTERNATOR, turbine
Includes items 37a & 37b
1
37a
{
110073 S O-RING, Viton 1
37b 185124 S CUSHION 1
38 185118 VALVE, electrostatic 1
39 224194 SHAFT ASSY., air valve 1
40 185115 NUT, packing 1
41 { 111508 O-RING, trigger valve; fluoroelastomer 1
42 { 105452 U-CUP, PTFE 1
43 222321 VALVE ASSY., fan air
Includes items 43b–43e
1
43b 105681 S RING, retaining 1
43c 191805 S KNOB, fan air adjustment 1
43d 185090 S HOUSING, valve 1
43e { 103557 S O-RING, Viton 2
44 185116 SPRING, compression, air valve 1
45 238895 VALVE ASSY., fluid adjustment
Includes items 45a–45e
1
45a 186826 S STEM, fluid adjustment 1
45b 111516 S O-RING, CV75 1
45c 186822 S KNOB 1
45d 191794 S SLEEVE, guide 1
45e 191795 S STOP, sleeve 1
46 107107 REGULATOR, disc 1
47 110082 RING, retaining 1
62 } 191744 TOOL, multi 1
63 } 107460 WRENCH, barrel 1
66 185103 TUBE, exhaust; polyurethane 1
67 110231 CLAMP, exhaust tube 1
69 } 110086 TOOL, hex key, allen wrench; 2 mm 1
71 }Y 180060 SIGN, warning, English
See Accessories for additional signs
1
72 } 180209 COVER, gun; Order Part No. 218374
for package of 10
1
76 } 235300 BRACKET, gun hanging 1
77 } 185079 PLUG, optional, to install in place of
item 31
1
* These parts are included in Fluid Seal Repair Kit 223020,
which may be purchased separately.
{ These parts are included in Air Seal Repair Kit 223021,
which may be purchased separately.
} Parts not shown.
Y Replacement Danger and Warning labels, signs, tags and
cards are available at no cost.
