4 www.goodmanmfg.com SS-CPH90-150 SS-CPH90-150 www.goodmanmfg.com 5
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
roduct
S
PecificationS
— 10 t
onS
CPH120
***3B***A*
CPH120
***3V***A*
CPH120
***4B***A*
CPH120
***4V***A*
CPH120
***7B***A*
CPH120
***7V***A*
Cooling Capacity
Total BTU/h
118,000 116,000 118,000 116,000 118,000 116,000
Sensible BTU/h 87,300 84,700 87,300 84,700 87,300 84,700
EER / IEER 11.5 / 11.5 11.3 / 12.6 11.5 / 11.5 11.3 / 12.6 11.5 / 11.5 11.3 / 12.6
Decibels 83 83 83 83 83 83
ARI Reference #s 5104783 5696560 5104783 5696560 5104783 5696560
Heating Capacity
BTU/h (47° F)
120,000 120,000 120,000 120,000 120,000 120,000
COP (47°F) 3.4 3.4 3.4 3.4 3.4 3.4
BTU/h (17° F) 56,000 56,000 56,000 56,000 56,000 56,000
COP (17°F) 2.4 2.4 2.4 2.4 2.4 2.4
Evaporator Motor / Coil
Motor Type
Belt Drive 2-Speed Belt Belt Drive 2-Speed Belt Belt Drive 2-Speed Belt
Indoor Nominal CFM 4,000 3,500 4,000 3,500 4,000 3,500
Indoor motor FLA (Cooling) 7.8 6.4 3.9 3.3 2.5 2.4
Horsepower - RPM 2.0/1725 2.0/1725 2.0/1725 2.0/1725 2.0/1725 2.0/1725
Piston Size (Cooling) 0.086 0.086 0.086 0.086 0.086 0.086
Expansion Device Orifice Orifice Orifice Orifice Orifice Orifice
Filter Size (No. = 4) 16" x 24" x 2" 16” x 24” x 2” 16” x 24” x 2” 16” x 24” x 2” 16” x 24” x 2” 16” x 24” x 2”
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge Cir #1 & #2 (oz.) 225 / 225 225 / 225 225 / 225 225 / 225 225 / 225 225 / 225
Evaporator Coil Face Area (ft²) 10.2 10.2 10.2 10.2 10.2 10.2
Rows Deep/ Fins per Inch 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14
Belt Drive Evap Fan Data
# of Wheels (D x W)
(1) 15" x 15" (1) 15" x 15" (1) 15" x 15" (1) 15" x 15" (1) 15" x 15" (1) 15" x 15"
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74 VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX50 AX51 AX50 AX51 AX50
Condenser Fan / Coil
Quantity of Condenser Fan Motors
2 2 2 2 2 2
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,125 ⅓ - 1,125
Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3
Outdoor Nominal CFM 7,200 7,200 7,200 7,200 7,200 7,200
Face Area (ft²) 32.4 32.4 32.4 32.4 32.4 32.4
# Coils / Rows Deep - Fins per Inch 2 / 2 - 22 2 / 2 - 22 2 / 2 - 22 2 / 2 - 22 2 / 2 - 22 2 / 2 - 22
Piston Size (Heating) 0.064 0.064 0.064 0.064 0.064 0.064
Compressor
Quantity / Type / Stage
2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1
Compressor RLA / LRA ea. 16 / 110.0 16 / 110.0 7.8 / 52.0 7.8 / 52.0 5.7 / 38.9 5.7 / 38.9
Electrical Data
Voltage/Phase/ Frequency
208-230/3/60 208-230/3/60 460/3/60 460/3/60 575/3/60 575/3/60
Belt-Driven Standard Max Static 1.4 1.4 1.4 1.4 1.4 1.4
Outdoor Fan RLA ea. 2.40 2.40 1.20 1.20 0.90 0.90
Total Unit Amps 45 43 22 21 16 16
Min. Circuit Ampacity¹ 49 47 24 23 17 17
Max. Overcurrent Protection (amps)² 60 60 30 30 20 20
Entrance Power Supply & Control Voltage Locating Dimple Locating Dimple Locating Dimple Locating Dimple Locating Dimple Locating Dimple
Operating Weight/Shipping (lbs) 1285/ 1310 1285/ 1310 1285/ 1310 1285/ 1310 1285/ 1310 1285/ 1310
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
