Goodman Mfg CPH COMMERCIAL SS-CPH90-150 - Manual (Page 4)

4 www.goodmanmfg.com SS-CPH90-150 SS-CPH90-150 www.goodmanmfg.com 5
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
roduct
S
PecificationS
— 8½ t
onS
CPH102
***3B***A*
CPH102
***4B***A*
CPH102
***7B***A*
Cooling Capacity
Total, BTU/h
102,000 102,000 102,000
Sensible BTU/h 73,440 73,440 73,440
EER / IEER 11.1 / 11.2 11.1 / 11.2 11.1 / 11.2
Decibels 83 83 83
ARI Reference #s 5104782 5104782 5104782
Heating Capacity
BTU/h (47°F)
102,000 102,000 102,000
COP (47°F) 3.4 3.4 3.4
BTU/h (17°F) 55,500 55,500 55,500
COP (17°F) 2.25 2.25 2.25
Evaporator Motor / Coil
Motor Type
Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,400 3,400 3,400
Indoor Motor FLA (Cooling) 7.8 3.9 2.3
Horsepower - RPM 1725 1725 1725
Piston Size (Cooling) 0.08 0.08 0.08
Filter Size (Qty) (4) 16” x 24” x 2” (4) 16” x 24” x 2” (4) 16” x 24” x 2”
Drain Size (NPT) 3/4” 3/4” 3/4”
R-410A Refrigerant Charge Cir #1 & #2 (oz.) 205 / 205 205 / 205 205 / 205
Evaporator Coil Face Area (ft²) 10.2 10.2 10.2
Rows Deep / Fins per Inch 4 / 14 4 / 14 4 / 14
Belt Drive Evap Fan Data
# of Wheels (D x W)
1 (15” x 12”) 1 (15” x 12”) 1 (15” x 12”)
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quantity of Condenser Fan Motors
2 2 2
Horsepower - RPM 1/4” - 1,090 1/4” - 890 1/4” - 1,075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 7,600 7,600 7,600
Face Area (ft²) 16.19 16.19 16.19
Rows Deep / Fins per Inch 2 / 22 2 / 22 2 / 22
Piston Size (Heating) 0.059 0.059 0.059
Compressor
Quantity / Stage/ Type
2 / Single/ Scroll 2 / Single/ Scroll 2 / Single/ Scroll
Compressor RLA / LRA ea. 14.5 / 98 6.3 / 55 6.0 / 41
Electrical Data / Static
Voltage / Phase / Frequency
230 / 3 / 60 460 / 3 / 60 575 / 3 / 60
Standard Max Static 1” 1 1
Outdoor Fan FLA ea. 1.4 0.8 0.6
Total Unit Amps 39.6 18.1 15.5
Min. Circuit Ampacity¹ 43.2 19.7 17
Max. Overcurrent Protection (amps)² 50 25 20
Entrance Power Supply & Control Voltage Locating Dimple Locating Dimple Locating Dimple
Operating Weight (lbs) 1285 1285 1285
Ship Weight (lbs) 1310 1310 1310
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
