308870 5
Troubleshooting
WARNING
INJECTION HAZARD
To reduce risk of serious injury, including fluid injection or splashing in eyes or on skin, or injury from
moving parts, always follow Pressure Relief Procedure Warning, page 4, before checking, adjust-
ing, cleaning or shutting down sprayer.
PROBLEM CAUSE SOLUTION
Engine won’t start Engine switch is OFF Turn engine switch ON
Engine is out of gas Refill gas tank. Honda Engines Owner’s Manu-
al.
Engine oil level is low Try to start engine. Replenish oil, if necessary.
Honda Engines Owner’s Manual.
Spark plug cable is disconnected or damaged Connect spark plug cable or replace spark
plug
Cold engine Use choke
Fuel shutoff lever is OFF Move lever to ON position
Oil is seeping into combustion chamber Remove spark plug. Pull starter rope 3 or 4
times. Clean or replace spark plug. Try to start
engine. Keep sprayer upright to avoid oil seep-
age.
Engine operates, but dis- Pressure control switch is OFF Turn pressure control switch ON.
placement pump does not
operate
Pressure setting is too low Turn pressure adjusting knob clockwise to
increase pressure.
Fluid filter (318) is dirty Clean filter. Page 22.
Tip or tip filter is clogged Clean tip or tip filter. Manual 309091.
Displacement pump piston rod is stuck due to
dried paint Repair pump. Manual 308798.
Roller bearings are worn or damaged Replace connecting rod. Page 7.
Drive housing is worn or damaged Replace drive housing. Page 7.
Electrical power is not energizing clutch field Check wiring connections. Page 11.
Reference control board diagnostics. Page 14.
With pressure control switch ON and pressure
turned to MAXIMUM, use a test light to check
for power between clutch terminals on control
board.
Remove black clutch wires from control board
and measure resistance across wires. At 70
_
F, the resistance must be between 1.7
±
0.2 Ω ; if
not, replace clutch coil 241121.
Have pressure control checked by authorized
Graco dealer.
Clutch is worn or damaged Replace clutch. Page 9.
Pinion assembly is worn or damaged Repair or replace pinion assembly. Page 9.
