Graco Inc. Xtreme 309329 - Manual (Page 2)

2 309329
List of Models/Liste des modèles/
Liste der Modelle/Lista de modelos
B–I = Built–in Filter
HD = Heavy Duty Cart
LW = Light Weight Cart B–I = Filtre incorporé
HD = Cariot type lourd
LW = Chariot type léger E–F = Eingebauter Filter
RF = Robustes Fahrgestell
LF = Leichtes Fahrgestell B–I = Filtro incorporado
HD = Carro para tareas pesadas
LW = Carro para tareas ligeras
Part
No.
Réf. No
Teile-
Nr.
Ref.
Pieza
Series
Série
Serie
Series
Ratio / Pump
Rapport /
pompe
Überset-
zungs-
verhältnis /
Pumpe
Relación de
presión /
Bomba
Pump No.
No Réf. de la
pompe.
Pumpen-Nr.
No bomba
Lower
Part No.
Bas de
pompe no
Unterpumpe
Teile-Nr.
Base de
bomba,
ref. pieza
Gun No.
Pistolet
Pistole
Pistola
Hose No.
Flexible
Schlauch
Manguera
B–I
E–F
HD
RF
LW
LF Maximum Fluid
Working Pressure
Pression de service
produit maximum
Zulässiger Material-
Betriebsüberdruck
Presión máxima
de fluido
Maximum Air
Input Pressure
Pression d’entrée
d’air maxi
Zul. Luft-Eingangs-
druck
Aire máximo
Presión de entrada
244458 A
33:1
Bulldog
244457 244413 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
244459 A
33:1
RIQ Bulldog
244464 244413 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
244460 A
33:1
Bulldog
244457 244413 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
244461 A
33:1
Bulldog
244457 244413 238591 244516 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
246843 A
33:1
Bulldog
246869 246866 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
253004 A
33:1
Bulldog
244457 244413 235628 215226 X X
22.8 MPa
(228 bar) (3300 psi)
.7 MPa
(7.0 bar) (100 psi)
244466 A
41:1
Bulldog
244465 244411 X X
28.3 MPa
(283 bar) (4100 psi)
.7 MPa
(7.0 bar) (100 psi)
244468 A
41:1
Bulldog
244465 244411 238591 244516 X X
28.3 MPa
(283 bar) (4100 psi)
.7 MPa
(7.0 bar) (100 psi)
253005 A
41:1
Bulldog
244465 244411 235628 215226 X X
28.3 MPa
(283 bar) (4100 psi)
.7 MPa
(7.0 bar) (100 psi)
244471 A
45:1
King
244470 244417 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar) (100 psi)
244472 A
45:1
Quiet King
245138 244417 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar) (100 psi)
244473 A
45:1
King
244470 244417 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
244474 A
45:1
King
244470 244417 238591 244516 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
244475 A
45:1
King
244470 244417 238591 244516 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
246846 A
45:1
King
246871 246868 238591 244516 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
248838 A
45:1
King
245119 244416 X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
246844 A
45:1
Quiet King
246870 246868 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
246845 A
45:1
King
246871 246868 X X
31.0 MPa
(310 bar) (4500 psi)
.7 MPa
(7.0 bar)100 psi
