Frame parts list – Grizzly G0459P User Manual
Page 49
Model G0459/G0459P (Mfg. 7/11+)
-47-
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
1
P0459001
FRAME
32V3
P0459P032V3
FRONT PANEL V3.01.11
2
PN02
HEX NUT 5/16-18
33V2
P0459033V2
PUSH BUTTON SWITCH V2.03.09
3
PW07
FLAT WASHER 5/16
34
PN02
HEX NUT 5/16-18
4
P0459004
SIDE PANEL
40
PW07
FLAT WASHER 5/16
4
P0459P004
SIDE PANEL
44
PN05
HEX NUT 1/4-20
5
P0459005
HANDLE
45
PB05
HEX BOLT 1/4-20 X 3/4
5-1
PCAP09
CAP SCREW 5/16-18 X 5/8
46V2
P0459046V2
PC BRD CONSOLE UNIT V2.03.09
6
P0459006
SPROCKET V1
54
P0459054
VARIABLE SPEED CTL KNOB
7-1
P0459007-1
SPROCKET SHAFT
54-1
P0459054-1
POTENTIOMETER
7-2
P0459007-2
SPROCKET
55
P0459055
SPEED INDICATOR LABEL
8-1
P0459008-1
TABLE LEAD SCREW (1)
56V2
P0459056V2
SWITCH BOX V2.03.09
8-2
P0459008-2
TABLE LEAD SCREW (2)
56V2
P0459P056V2
SWITCH BOX V2.03.09
8-3
P0459008-3
BUSHING
57
PFS17
FLANGE SCREW 10-24 X 1/2
8-4
P0459008-4
WORM GEAR 25-TEETH
57-1
PN07
HEX NUT #10-24
8-5
PK06M
KEY 5 X 5 X 10
57-2
PS06
PHLP HD SCR 10-24 X 3/8
8-6
P0459008-6
BUSHING
59
PTLW02M
EXT TOOTH WASHER 5MM
8-7
PW01
FLAT WASHER 1/2
99
PAW03M
HEX WRENCH 3MM
9
P0459009
ELEVATION CHAIN
100
P0459100
DUST SCOOP
10
P0459010
FRONT BRACE
100
P0459P100
DUST SCOOP
10
P0459P010
FRONT BRACE
101
P0459101
WORM GEAR SHAFT BRACKET
11
P0459011
DEPTH SCALE
103
P0459103
SHAFT MOUNT
12
P0459012
RIGHT SUPPORT ARM
104
P0459104
WORM GEAR
12-1
PS41
PHLP HD SCR 6-32 X 1/4
107
P0459107
BUSHING
12-2
PN12
HEX NUT 6-32
108
PB19
HEX BOLT 1/4-20 X 1/2
13
G2977
UNIVERSAL DUST PORT 2-1/2"
109
P0459109
COLLAR
14
P0459014
TOP COVER
110
P0459110
WORM GEAR MOUNT WASHER
14
P0459P014
TOP COVER
111
P0459111
WIRES
14-1
P0459014-1
HINGE
112V2 P0459112V2
GEAR COVER V2.07.11
15
P0459015
REAR BRACE
112V2 P0459P112V2
GEAR COVER V2.07.11
15
P0459P015
REAR BRACE
113
P0459113
CRANK HANDLE
16V2
P0459016V2
REAR PANEL V2.03.09
113
P0459P113
CRANK HANDLE
16V2
P0459P016V2
REAR PANEL V2.03.09
114
P0459114
HANDLE
17
PSS03
SET SCREW 1/4-20 X 3/8
115
PN08
HEX NUT 3/8-16
18
P0459018
MOTOR PULLEY
117
PW07
FLAT WASHER 5/16
19
PK110
KEY 1/4 X 1/4 X 1
118
PB03
HEX BOLT 5/16-18 X 1
20V2
P0459020V2
MOTOR 1.5HP 110V 1PH V2.03.09
119
PSS11
SET SCREW 1/4-20 X 1/4
20-1
P0459020-1
MOTOR BRACKET
120
P0459120
OL RELAY YS 20A
20-2
P0459020-2
S CAP 300M 125V 1-1/2 X 3-1/8
121
P0459121
HEX NUT SIZE M11-1
20-3
P0459020-3
CAPACITOR COVER
122
P0459122
JUMPER
20-4V2 P0459020-4V2 JUNCTION BOX V2.03.09
130
P0459130
PC BOARD COVER
20-5
P0459020-5
FAN COVER
132
P0459132
FRONT ELEVATION CHAIN GUARD
20-6
P0459020-6
MOTOR FAN
133
P0459133
REAR ELEVATION CHAIN GUARD
20-7
P0459020-7
CENTRIFUGAL SWITCH
134
PS06
PHLP HD SCR 10-24 X 3/8
22
PB07
HEX BOLT 5/16-18 X 3/4
135
PW03
FLAT WASHER #10
24
PW07
FLAT WASHER 5/16
136
PN07
HEX NUT #10-24
28
P0459028
FLANGE SCREW M3-.6 X 16
137
P0459137
PADLOCK STORAGE HOOK
29
PHTEK7
TAP SCREW #8 X 3/8
138
P0459138
SWITCH PADLOCK
30-1V2 P0459030-1V2 POWER CORD V2.03.09
209
G9987
GRIZZLY NAMEPLATE-MINI
30-2V2 P0459030-2V2 MOTOR CORD V2.03.09
209-1
PHTEK24
TAP SCREW #5 X 3/8
30-3V2 P0459030-3V2 VS POWER CORD V2.03.09
211
P0459211
COVER LOCK KNOB
30-4V2 P0459030-4V2 DC MOTOR CORD V2.03.09
212V3 P0459212V3
MACHINE ID LABEL CSA V3.07.11
30-5
P0459030-5
CONTROL WIRE
212V3 P0459P212V3
MACHINE ID LABEL CSA V3.01.11
31V2
P0459031V2
STRAIN RELIEF MGB16 V2.07.11
223
PLABEL-75
POLAR BEAR LOGO 2-1/2 X 9-1/2
31-1
P0459031-1
STRAIN RELIEF 3/4"
224
PPAINT-24
POLAR BEAR WHITE TOUCH-UP PAINT
32V3
P0459032V3
FRONT PANEL V3.01.11
225
P0459P225
MODEL NUMBER LABEL
frame Parts List
