GN-A11G Wireless LAN Access Point
Front Panel
Y X
Z
LED
The Wireless LAN Access Point’s LEDs display information about the AP’s
status.
X Power
on
(Green LED)
When the LED is on, the power is supplied to GN-A11G.
Note: When you change the settings and save them, the power LED will be
temporarily off.
Y WLAN
(Green)
On
ADSL/Cable Modem is
connected to WAN port.
Flashing
Data is being transmitted
wirelessly.
Z LAN
(Green)
On
LAN port has detected a link with a 10/100
Mbps device.
Flashing Data is being transmitted wirelessly.
