Grandstream Networks, Inc. BT200 User Manual Page 26 of 37
Firmware 1.1.1.14 Last Updated: 12/2006
Quick IP Call Mode Dial an IP address under the same LAN segment by simply pressing the last octet
in the IP address.
In the Advanced Settings page the option "Use Quick IP-call mode", is set to No
by default. When this option is set to YES, and #XXX is dialed, where X is 0-9 and
XXX <=255, phone will make direct IP call to aaa.bbb.ccc.XXX where aaa.bbb.ccc
comes from the local IP address REGARDLESS of subnet mask.
#XX or #X are also valid so leading 0 is not required (but OK).
eg.
192.168.0.2 calling 192.168.0.3 just dial #3 follow by SEND or #
192.168.0.2 calling 192.168.0.23 just dial #23 follow by SEND or #
192.168.0.2 calling 192.168.0.123 just dial #123 follow by SEND or #
192.168.0.2 dial #3 and #03 and #003 has same effect --> call 192.168.0.3
NOTE: If you have a SIP Server configured, Direct IP-IP call will still work. However,
if you are using STUN, Direct IP-IP call will also use STUN.
Lock keypad update If this parameter is set to “Yes”, the configuration updates via keypad for Menu Item
7, 9, 12 are disabled.
T ABLE 11: I NDIVIDUAL S ETTINGS D EFINITIONS
Account Active This field indicates whether the account is active or not. The default value for the
primary account Account 1 is Yes. The default values for the other three accounts
are No.
Account Name A name to identify an account which will be displayed in LCD.
SIP Server SIP Server’s IP address or Domain name provided by VoIP service provider.
Outbound Proxy IP address or Domain name of Outbound Proxy, or Media Gateway, or Session
Border Controller. Used by BT200 for firewall or NAT penetration in different
network environment. If symmetric NAT is detected, STUN will not work and ONLY
outbound proxy can provide solution for it.
SIP User ID User account information, provided by VoIP service provider (ITSP), usually has the
form of digit similar to phone number or actually a phone number.
Authenticate ID SIP service subscriber’s Authenticate ID used for authentication. Can be identical to
or different from SIP User ID.
Authenticate
Password SIP service subscriber’s account password for BT200 to register to (SIP) servers of
ITSP.
Name SIP service subscriber’s name which will be used for Caller ID display.
Use DNS SRV: Default is No. If set to Yes the client will use DNS SRV to look up server.
User ID is Phone
Number If the BT200 has an assigned PSTN telephone number, this field should be set to
“Yes”. Otherwise, set it to “No”. If “Yes” is set, a “user=phone” parameter will be
attached to the “From” header in SIP request
