DTMF Payload Type This parameter sets the payload type for DTMF using RFC2833.
Syslog Server
The IP address or URL of System log server. This feature is especially useful for
ITSP (Internet Telephone Service Provider).
Syslog Level
Select the BT200 to report the log level. Default is NONE. The level is one of
DEBUG, INFO, WARNING or ERROR. Syslog messages are sent based on the
following events:
1.
product model/version on boot up (INFO level)
2.
NAT related info (INFO level)
3.
sent or received SIP message (DEBUG level)
4.
SIP message summary (INFO level)
5.
inbound and outbound calls (INFO level)
6.
registration status change (INFO level)
7.
negotiated codec (INFO level)
8.
Ethernet link up (INFO level)
9.
SLIC chip exception (WARNING and ERROR levels)
10. memory exception (ERROR level)
The Syslog uses USER facility. In addition to standard Syslog payload, it contains
the following components:
GS_LOG: [device MAC address][error code] error message
Example
: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000]
Ethernet link is up
NTP server
URI or IP address of the NTP (Network Time Protocol) server, which will be used by
the phone to synchronize the date and time.
Allow DHCP Option
42 to override NTP
server
DHCP Option 42 specifies a list of IP addresses for Network Time Protocol (NTP)
servers available to the client. If you choose yes, BT200 will use the NTP servers
resolved from DHCP, instead of the one you specified in the "NTP Server" option
above.
Distinctive Ring
Tone
Customer Ring Tone 1 to 3 with associate Caller ID: when selected, if Caller ID is
configured, then the device will ONLY sound this ring tone when the incoming call is
from the Caller ID, device will use System Ring Tone for all other calls.
When selected but no Caller ID is configured, the selected ring tone will be used for
all incoming calls.
Disable Call Waiting Default is No.
