Real-time Clock:
Synchronized to Internet time server
Time zone configurable via web browser
AM/PM indicator
Call Logs and IP Address Separator Icons:
01-10 for CALLED history (dialed number)
01-10 for CALLERS history (Incoming caller ID)
Numbers and Characters:
0 – 9, “* key” = └, “# key“= ┘
PM
AM
G
ETTING
F
AMILIAR WITH
K
EYPAD
The BT200 keypad is the same as a traditional phone, with additional feature functionality including
speaker, menu keys, LCD navigation keys, and advanced feature keys which include hold, transfer,
conference and flash.
F IGURE 3: BT200 K EYPAD I LLUSTRATION
Navigation
Keys Message
Button & LED
Menu and
Call Keys
Advanced
Feature
Buttons
Speaker, Send
& Mute/Del
