Grandstream Networks, Inc. BT200 User Manual Page 18 of 37
Firmware 1.1.1.14 Last Updated: 12/2006
Menu Item Menu Functions
11
Display “[11] ring 0”
Press MENU to hear the selected ring tone, press ‘↓’ or ’↑’ to select the stored ring tones.
There are 3 available ring-tones: ring 0 (default), ring 1 and ring 2. ring 3 is unavailable or
unsupported.
Press MENU to select and exit.
Factory Reset
Display “ -- rESEt --”. Please be very careful when using this function.
Two options: factory reset or manual reboot.
Factory Reset:
1. Key in the physical / MAC address on back of the phone.
2. Press MENU to reset phone to FACTORY DEFAULT settings. All your setting will
be erased.
Manual Reboot: Press MENU without keying anything.
Others
When phone is powered on and time is displayed
Press ‘↓’ or ’↑’, Display “ ring [4] ”, press ‘↓’ or ’↑’ again to hear and adjust the ring tone
volume, from 0 (off) to 7 (maximum), off and on hook to set
Press SPEAKERPHONE button, or off hook and pick up handset, press ‘↓’ or ’↑’ to adjust the
speakerphone/headset or handset volume.
C ONFIGURATION WITH W EB B ROWSER
The BT200 has an embedded Web server that will respond to HTTP GET/POST requests. It also has
embedded HTML pages that allow a user to configure the IP phone through any web browser.
Access the Web Configuration Menu
The IP Phone Web Configuration Menu can be accessed by the following URI: http://Phone-IP-Address
where the Phone-IP-Address is the IP address of the phone. To find your IP address, press MENU and
select the Status item to see “IP: IP Address”.
NOTE: When typing the IP address into a browser, strip out the leading “0” as the browser will parse in
octet. e.g. if the IP address is: 192.168.001.014, please type in: 192.168.1.14.
