Galaxy Metal Gear 65 - Manual (Page 108)

Galaxy 65 User Guide
88
Caution All mandatory settings must be observed in order for the Galaxy 65 system to function correctly.
Note To set Host 1Gb use the Ethernet connected configurator.
Table 7–9 Ops Panel Switch Functions (Default settings for Galaxy 65 LRC usage at 2Gb/s)
Switch
Number
Function Recommended
Setting
Definition
1 Loop Select,
Dual (2x8) Off LRC operates on two loops of 8 drives
Mandatory
2 Not Used Note: on Galaxy 65-FC2 enclosures this must be set On.
3 Not Used
4 Not Used
5 & 6 Not Used
7 & 8 Drive Loop Speed
Select Sw7 Sw8
On Off Force 2Gb/s
Off Off Force 1Gb/s
9 & 10 Drive Addressing
Mode Selection Sw9 Sw10
On Off Mode 2, 2x8 mode. Mandatory
11 SOFT SELECT On Select Functions using the hardware
switches
12 Not Used
