4"
18" Min.
30" Wide Models 4"
36" Wide Models 4"
48" Wide Models 8"
35-3/8" Max. for Counter Level
36-3/4" Max. with Range Leveling Legs Fully Extended
1-1/2"
Gas Supply
Electrical Supply
Cooking Surface
13"
Max.
30"/36" Wide Models 4"
48" Wide Models 8"
30" Wide Models 8"
36" Wide Models 12"
48" Wide Models 16"
30" Wide Range Hood
Or
36" Wide Range Hood
Or
48" Wide Range Hood
12" Min. to
Combustible
Material
Each Side
36" Min. to
Combustible
Material From
Cooking Surface
12"
30" Wide Range Models
35-1/4"-36-3/4"
26-3/4"
29-7/8"
22"
1-1/2"
Optional B
acksplas
h
9"
9" High Backsplash
22" High
Backsplash
with Shelf
9-1/2"
3/4"
22"
9"
27-3/8"
36" Min.
to Combustibles
26-3/4"
29-1/4"
43-7/8"
0" Clearance
NOTE: Refer
to Vent Hood
Installation
Instructions
for hood height
above the range.
5
PRODUCT DIMENSIONS AND CLEARANCES
Design Information
