CAUTION:
THESE RANGES SHOULD BE INSTALLED
IN CONJUNCTION WITH A SUITABLE
OVERHEAD VENT HOOD. Due to the high heat capacity
of this unit, particular attention should be paid to the
hood and duct work installation to assure it meets
local building codes.
MISE EN GARDE :
CES CUISINIÈRES DOIVENT ÊTRE
MONTÉES CONJOINTEMENT AVEC UNE
HOTTE À ÉVACUATION DE PLAFOND APPROPRIÉE.
Étant donné la grande capacité thermique de cet
appareil, une attention particulière doit être portée
au montage de la hotte et du système de gaines pour
s’assurer qu’il est conforme aux codes du bâtiment
locaux.
Standard countertop and island installations:
A 1200 CFM hood is recommended for 48" ranges.
A 600 CFM hood is recommended for 30" and 36" Ranges.
Hoods should be 24" min. deep and the same width as
the cooktop.
Check local building codes for the proper method of
gas range installation. Local codes vary. Installation,
electrical connections and grounding must comply
with applicable codes. In the absence of local codes,
the gas range should be installed in accordance with
the National Fuel Gas Code ANSI 223.1, latest
edition and National Electrical Code ANSI/NFPA 70,
latest edition.
CAUTION:
These ranges weigh up to 600 pounds.
Some disassembly will reduce the weight
considerably. Due to the weight and size of the range
and to reduce the risk of personal injury or damage
to the product, TWO PEOPLE ARE REQUIRED FOR
PROPER INSTALLATION.
MISE EN GARDE :
Ces cuisinières pèsent jusqu’à
272 kg (600 lb). Tout démontage réduira
considérablement leur poids. En raison du poids et
de la taille de la cuisinière, dont la manipulation risque
d’entraîner des lésions corporelles ou des dommages
au produit, DEUX PERSONNES SONT NÉCESSAIRES
POUR PROCÉDER À UN MONTAGE ADÉQUAT.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
• IMPORTANT
– Save these instructions for
local inspector’s use.
• IMPORTANT
– Observe all governing codes
and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill Level – Installation of this range requires basic
mechanical and electrical skills.
• Completion time – 1 to 3 hours.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
WARNING:
This appliance must be properly grounded.
See “Electric Supply”, page 7.
AVERTISSEMENT :
Cet appareil doit être mis à la terre
adéquatement. Voir la section « Alimentation
électrique » à la page 7.
For Monogram local service in your area,
1.800.444.1845.
For Monogram Service in Canada, call
1.888.880.3030.
For Monogram Parts and Accessories, call
1.800.626.2002.
If you received a damaged range, you should contact
your dealer.
In the Commonwealth of Massachusetts:
• This product must be installed by a licensed plumber
or gas fitter.
• When using ball type gas shut off valves, they shall
be T-handle type.
• A flexible gas connector, when used, must not
exceed 3 feet.
