14 308-236
Technical Data
Category Data
Maximum fluid working pressure 5000 psi (345 bar)
Fluid orifice size Model 235–462: 0.037 in. (0.94 mm)
All other models: 0.090 in. (2.3 mm)
Wetted parts Stainless steel, Polyethylene, Polyurethane, Nylon, PTFE r
Weight 18 oz (510 g)
Inlet 1/4 npsm(m)
Maximum material temperature 120 _ F (50 _ C)
* Sound pressure level 78 dBa
* Sound power level 87 dBa
* Measured while spraying waterbase paint – gravity 1.36 through a 517 tip at 3000 psi (207 bar) per ISO 3744.
TPTFE r is a registered trademark of the DuPont Co.
Manual Change Summary
Updated manual per ECO F5413.
