S14 & PS14P (PoE) Convenient Switches
Installation and User Guide
23
www GarrettCom com
.
.
unit is mounted in a rack mount tray.
The Magnum PS14P Power Source
Switch requires a heavy-duty power supply of
-48VDC 1.4Amps (66 watts total
consumption) to provide 13-15w power on
each port to the PoE unit. The heavy duty Din
rail mounted, -48V DC power supply can be
purchased using this URL:
http://www.lanstore.com/ps.htm
Note:
The 8-15vdc option is also present, but can only be used to power the PS14P unit
when no PoE devices are attached. While using a 12vdc Adaptor to power on the switch,
the unit will not function as a PoE power source switch but as a non-PoE switch only.
