12

Installation

30" Built-I n Convection Oven s

• Grasp door firmly on both sides.
• Slide the hinge slots in the bottom of the door over

the hinges.

• Push the door all the way in against oven.
• Open the door fully and push hinge latches down,

as illustrated, on both sides to secure.

• Close the door and open slowly to be sure it moves

smoothly.

Step 6
Replace the
oven door

Hinge Latch
Normal Position

Step 7
Connect
electrical

CAUTION

WARNING

Electrical Shock Hazard
• Electrical ground is required on this

appliance.

• Do Not connect to the electrical

supply until appliance is
permanently grounded.

• Disconnect power to the junction box before

making the electrical connection.

• This appliance must be connected to a grounded,

metallic, permanent wiring system, or a grounding
connector should be connected to the grounding
terminal or wire lead on the appliance.

Failure to do so could result in a fire, personal
injury or electrical shock.

• When connecting to a 3-conductor branch circuit:

– Connect oven red lead to branch circuit red lead.
– Connect oven black lead to branch circuit black

lead.

– Connect oven bare copper conductor and white

lead to branch circuit neutral lead (white or gray).

Note:

Use copper wire only.

• When connecting to a 4-conductor branch circuit:

– Connect oven red lead to branch circuit red lead.
– Connect oven black lead to branch circuit black

lead.

– Break connection between oven white lead and

oven bare copper conductor.

– Connect oven white lead to branch circuit neutral

lead (white or gray).

– Connect oven bare copper conductor to branch

circuit ground lead (green or bare copper).
