3-6
[INITIAL SETTING 1]
1 [FUNCTIONS(4)]
2 HL ALIGN
EBL 0.0
°
3 TIMING ADJ
VRM 00.00
4 ANT HGT 5m/7m/10m/15m/
20m/30mMORE
5 LOG PULSE 200P
6 [OWN SHIP INFORMATION]
7 MBS
MBS TIMING VRM 0
MBS LEVEL EBL 0
8 ON TIME 000000.0H
9 TX TIME 000000.0H
0 [INITIAL SETTING(2)]
[INITIAL SETTING 2]
1 [INITIAL SETTING(1)]
2 LOG GYRO INPUT
LOG
PULSE/SERIAL DATA
GYRO
AD/10/SERIAL DATA
3 OWN SHIP VECTOR COMPASS/COURSE
4 KEY BEEP ON/OFF
5 SCANNER STOPPED ST-BY/TX
6 VIDEO SIG ANALOG/DIGITAL
7 ALARM LEVEL 4/5/6/7
8 DISPLAY MAIN/SUB
9 SECTOR BLKG OFF/ON
000
° → 000 °
000 ° → 000 °
0 [INITIAL SETTING(3)]
[INITIAL SETTING 3]
1 [INITIAL SETTING(2)]
2 TRAILS RESTART
OFF/ON
3 ECHO AVG W/O GYRO OFF/ON
4 HEAD UP TB SCALE DEG/16POINT
5 CTR ECHO STRETCH OFF/ON
6 VIDEO CONTRAST 1/2/3
7 MAXIMUM RANGE 72/96/120
8 ECHO FULL COLOR OFF/ON
9 INDEX LINES 2/3/6
0 [INITIAL SETTING(4)]
[INITIAL SETTING 4]
1 [INITIAL SETTING(3)]
2 MODEL
FR-2115, 2125/
OTHER X-BND/
FR-2165DS, 2135SW/
OTHER S-BND
3 TYPE R/N/G/D
4 CTR STC CURVE L/M/H
5 RJ-7 OFF/ON
6 RJ-8 OFF/ON
ANT A
FR-2115,
2125/
OTHER X-BND/
FR-2165DS, 2135SW/
OTHER S-BND
ANT B
FR-2115,
2125/
OTHER X-BND/
FR-2165DS, 2135SW/
OTHER S-BND
7 SHIP’S TYPE DEEP SEA/FISHING/
LONG LINE FISHING
8
9 CABLE LENGTH
500m/5000m
0 FACTORY DEFAULT
[OWN SHIP INFORMATION]
1 [INITIAL SETTING(1)]
2 SHIP’S LENGTH
000m
3 SHIP’S WIDTH 00m
4 RADAR POSN FOR BOW 000m
FOR PORT 00m
5 NAV ANT POSN FOR BOW 000m
FOR PORT 00m
6 TURN RATE 00KT
00.0
°
/ s
00KT
00.0
° / s
7 SPEED RATE 00KT
0.00KT/s
00KT
0.00KT/s
Press [RADAR MENU] [0] [0] [0] [2]
Press [0]
Press [0]
Press [0]
Press [6]
INITIAL SETTING1 menu
Keying sequence: [RADAR MENU] [0] [0] [0] [2]
HL ALIGN: Aligns heading.
TIMING ADJ: Adjusts sweep timing.
ANT HGT: Enter height of scanner above water. Select from 5 m, 7 m, 10 m, 15
m, 20 m, or more than 30 m.
LOG PULSE: Enter speed log's pulse rate.
