Installation Conditions
3.3 Cable Connections
3.3.1 Device connector
The disk drive has the connectors and terminals listed below for connecting
external devices. Figure 3.7 shows the locations of these connectors and terminals.
Connector,
setting pins
PCA
Figure 3.7 Connector locations
3-8
C141-E258
