MOTOROLA
Chapter 7. Electrical Characteristics
7-3
PRELIMINARYÑSUBJECT TO CHANGE WITHOUT NOTICE
Figure 7-2. MII Transmit Signal Timing Diagram
7.3.3 MII Async Inputs Signal Timing (CRS, COL)
Table 7-3 provides information on the MII async inputs signal timing, shown in Figure 7-3.
Figure 7-3 shows the MII asynchronous inputs signal timing diagram.
Figure 7-3. MII Async Inputs Timing Diagram
Table 7-3. MII Async Inputs Signal Timing
Num
Characteristic
Min
Max
Unit
M9
CRS, COL minimum pulse width
1.5
Ñ
TX_CLK period
M6
TX_CLK (input)
TXD[3:0] (outputs)
TX_EN
TX_ER
M5
M7
M8
CRS, COL
M9
F
re
e
sc
a
le
S
e
m
ic
o
n
d
u
c
to
r,
I
