Fostex VF80 - Manual (Page 107)

107
Save/Load of Song data
Press the [SETUP] key to enter the setup mode.
The display shows the screen for selecting the setup
menu.
Use the [JOG] dial to select (highlight) “Load PGM”
and press the [ENTER/YES] key.
The display shows the screen for selecting a load de-
vice, where
“IDE” is flashing.
Loading backup data from a CD-RW drive
Do not carry out any VF80 key operation until
the access process to the CD-RW/CD-R disc is
completed.
If you load song data which is saved to more
than one disc, set DISC-1 first.
If you set the other disc and go on the follow-
ing procedure, the VF80 automatically recog-
nized that the disc order i s not correct and
the display shows
“Wrong Disk” , followed by
“Illegal No!” momentarily, and the disc is au-
tomatically ejected.
After turning on both the VF80, insert the disc to the
CD-RW drive.
While the desired backup number/title is shown on
the display, press the [ENTER/YES] key.
The display shows the screen for creating a new pro-
gram on the current drive, to which data will be loaded
(
“New PGM” lights).
When you load song data which is saved to more
than one disc, the display also shows the disc num-
ber currently set. The example below shows DISC-
1 is set.
By rotating the [JOG] dial, you can select a desired
program number/title from among available programs
in the VF80 current drive. You can also select
“Eject” .
If you select “Eject” and press the [ENTER/YES] key,
the disc is ejected
Flashing
Flashing
Light up
The following procedure describes how to load FDMS-3 song data.
We assume that the optional CD-RW drive (Model CD-1A) is already installed to the VF80 and a CD-RW or CD-
R disc on which the song data is recorded is set.
While “IDE” is flashing, press the [ENTER/YES] key.
After briefly showing the model name of the connected
CD-RW drive, the display shows the screen for select-
ing a load mode, where
“BkUp” (backup) is flashing.
To load song data saved, select “BkUp” .
To load a material from an audio CD, select “CD-DA” .
This procedure describes how to load song data, so
we select
“BkUp” here.
See “Loading from an audio CD” described later for de-
tails about how to load a material from an audio CD.
Flashing
While “BkUp” is flashing, press the [ENTER/YES] key.
The display shows the backup number and title, as
well as recorded space.
Flashing
1
2
3
4
5
6
