Fisher & Paykel DCS DD224P5 - Manual (Page 27)

25
SINGLE MODELS
US CA
Plumbing and drainage - OPTION 2 (connection)
1
3
2
1
4
DishDrawer® using Air Break with Drain Hose Joiner
9
10
Ensure hoses are routed
straight to joiner. Remove
excess hose material if
necessary.
Fit supplied
washer
