23
SINGLE MODELS
US CA
Plumbing and drainage - OPTION 1 (connection)
3
2
1
2
3
1
4
29 ½” - 34 ¾”
(750 -
882.5 mm)
DishDrawer® with Waste Disposal
If space is limited
for fixing, push hose
through drain hose
support to required
height 9
10
Fit supplied
washer
Ensure hoses are routed
straight to joiner. Remove
excess hose material if
necessary.
