Symptom 11 – FUJITSU fi-4120C2 User Manual
Page 94
78
*1) For details on requirements, see "6.2 Document Quality" (page. 87).
*2) For details on how to clean the ADF, see "3.2 Cleaning the ADF" (page. 45).
*3) For details on how to install the consumables, see "4 REPLACING CONSUM-
*4) For details on how to clean the consumables, see "3 DAILY CARE" (page. 43).
*5) For details on how to replace the consumables, see "4 REPLACING CONSUM-
Use the document that
satisfy the requirements. (*1)
NO
YES
Is there any debris in the ADF?
YES
Clean the ADF or remove
debris from the ADF. (*2)
NO
Correctly install the
consumable (Pick roller and
Pad ASSY), if needed. (*3)
YES
NO
Symptom 11
Paper jams occur frequently
Do the documents satisfy the
conditions described in
"6.2 Document Quality"?
Are all the consumables
(Pick roller and Pad ASSY)
installed correctly?
Is any of consumables
(Pick roller, Pad ASSY) dirty?
YES
Clean the dirty consumable.
(*4)
Is any of consumables (Pick roller
and Pad ASSY) worn out? (Check
the consumable counter)
Replace the consumable,
if needed. (*5)
NO
YES
NO
If you cannot solve the problem
after taking measures, check the
items in "5.3 Items to check before
contacting the dealer where you
bought the scanner" and contact
the dealer or an authorized
FUJITSU service provider.
