1.2 Loading Documents on the ADF for Scanning
fi-4120C2 Image Scanner Operator’s Guide 3
BASIC SCANNER OPERATIONS
1
1.2 Loading Documents on the ADF for Scanning
1. Align the edges of the documents.
1) Confirm that all the documents have the same width.
2) Check the number of sheets in the document stack.
The standard number of sheets that can be loaded on the scanner is as follows:
• A4-size paper or smaller that makes a document stack of 5mm or less
• Maximum 50 sheet at A4, 20 lb, or 80 g/m
2
2. Fan the documents as follows:
1) Lightly grip both ends of the document with both hands, and bend the document as fol-
lows.
2) Firmly holding the document with both hands, bend back the document as follows so that
the bent section rises up in the middle of the document as follows.
3) Repeat steps 1) to 2) a few times.
4) Rotate the document 90 degrees, and fan again.
3. Align the top of the documents.
5mm
