Color monitor 19T2
10 - English A26361-K616-Z100-2-5E19
Operating the OSD menu
To set the OSD menu, perform the following steps:
Ê Briefly press the Menu button to activate the OSD menu.
The main menu appears on the screen with icons for the setting functions.
A
OK
EXIT
SIZE/CENTER
GEOMETRY
COLOR
CONVERGENCE
LANGUAGE
OPTION
HELP
MENU
?
Ê Select the desired symbol with the arrow
buttons
and , e. g.
GEOMETRY .
(If you wish to exit the OSD menu, select
EXIT .)
The selected symbol has a colored
marking.
Ê Press the Menu button to display the
appropriate options window.
Depending on what options window is involved (here: GEOMETRY .), further icons are offered.
26
GEOMETRY
Ê If necessary, select a different symbol with
the arrow buttons
.
Ê Make the required setting using the arrow
buttons
.
All changes are stored automatically.
The OSD menu disappears after approx. 30
seconds. The OSD menu can be hidden
beforehand by pressing the menu button
(possibly several times).
Adjusting the contrast and brightness
The contrast and brightness can be adjusted directly with the arrow buttons and of
the control panel when the OSD menu is hidden. The set values are saved for all input signals.
i
You will increase the life of your screen if you adjust the contrast and brightness to
medium.
In the setting window for contrast and brightness, the horizontal frequency and refresh
rate of the current input signal are displayed as additional information.
