2-27
Item Part # Component
* 826-0877 Kit, Clamp Service (Contains 2 each of Items 1-3 and 1 of Item 4)
1 810-0396 Clamp Section (Requires 2 per connection)
2 809-0071 Nut, ¼–20
3 826-1375 Screw, 10–32 X ¾
4 816-0032 Seal (Connection Gasket)
5 826-1348 Cover, Clean-out (Pkg. of 5)
6 816-0021 Gasket, Clean-out
7 826-1382 Wing Nut, Clean-out Cover Retaining (Pkg. of 10)
8 900-0757 Cover, Drain End
9 823-0717 Full Vat, 15.5-inches Long
10 823-0718 End, Full Vat, 8.12-inches Long
* 813-0284 Nipple, 1-inch x ¾-inch (connects drain valve to drain tube)
11 Grommet, Drain Tube
816-0092 1.50-inch I.D.
816-0091 1.75-inch I.D. (used on FM I units built prior to February 1990 only)
12 826-1345 Washer, Drain Tube Retaining (Pkg of 25) (1⅜-in. ID x 2 3 /
16
-in. OD)
13 809-0347 Nut, Drain Tube Retaining
14 823-0731 Extension, Spreader Cabinet, 15.5-inches Long
15 823-0719 Drain Outlet, Fixed
16 806-4068 Drain Outlet Assembly, Swivel
17 823-1091 Drain Tube, Swivel
18 816-0083 O-Ring, 2.5-inches ID
19 823-1092 Collar, Drain
20 810-0388 Knob, Clamping
21 809-0115 Screw, 10–32
22 810-1569 Valve w/Handle, 1.25-inch Drain (for use on MJ45 units)
23 810-1568 Handle w/Lock, Drain Valve
24 810-1020 Valve, 1.25-inch Drain (for use on FM45 units)**
25 806-8137 Bracket, Drain Safety Switch
26 816-0220 Insulation, Drain Safety Switch
27 807-2103 Switch, Drain Safety
28 900-2841 Cover, Drain Safety Switch
29 809-0237 Nut, 4-40 Keps Hex
30 809-0540 Nut, ½-inch 2-Way Lock
31 810-0820 Handle, Drain Valve w/o Lock
32 816-0211 Sleeve, Drain Valve Handle
33 812-1226SP Extension, Drain
* * Not illustrated.
** For old-style valve with welded-on switch bracket, use 823-1363.
