2-23
ITEM PART # COMPONENT
1 802-0765 Label, Control Panel
2 802-1470 Label, Thermostat Dial
3 802-1473 Label, 15-Minute Mechanical Timer Bezel
4 910-1551 Bezel, 15-Minute Mechanical Timer
5 810-0334 Knob, Operating Thermostat
6 810-1287 Knob, 15-minute Mechanical Timer
7 810-1822 Knob, 15-Minute Electrical Timer Replacement
8 810-1823 Push Button, White 15-Minute Electrical Timer Replacement
9 807-1525 Light, White Melt Cycle Indicator, 24V
10 807-3498 Switch, Melt Cycle Rocker, 24V
11 807-3575 Plug, Blank Switch (used on units without melt cycle option)
12 826-1395 Plug, Snap-in Reducer, S/S (Pkg of 10)
13 826-1338 Bushing, Plastic, Thermostat Shaft (Pkg of 25)
14 810-0585 Timer, 15-minute Mechanical Basket Lift
15 Timer, 15-Minute Electrical Basket Lift
826-1552 100-120V
807-0401 208-240V
16 950-0246 Insulation, Double Electric Timer
17 809-0093 Screw, 6-32 X 3 /
16
-inch Slotted Flat Head
18 810-0276 Adapter, Shaft End
19 810-0999 Shaft, Flexible
20 809-0157 Set Screw
21 826-1361 Stop Screw (Pkg of 25)
22 809-0050 Nut, 5-32 Hex
23 900-2241 Bracket, Thermostat
24 900-2071 Bracket, Thermostat Shaft Guide
25 826-1371 Screw, #8 X ½-inch Slotted Hex Washer Head (Pkg. of 25)
26 910-4345 Panel, Thermostat Control without Timers
27 910-4344 Panel, Thermostat Control with Electric or Mechanical Timers
* 802-0336 Label, Frymaster Logo
* 806-4797 Alarm, Open Drain (Buzzer)
* Not illustrated.
NOTE: See Pages 2-16 and 2-17 for melt cycle timers.
