2-5
ITEM PART # COMPONENT
1 Mount, Modular Basket Lift**
200-2942 For use on units with 12-pin connectors
900-7655 For use on units with 6-pin connectors
2 806-5964SP Motor Assembly, Modular Basket Lift***
3 807-2133 Capacitor, 12.5 µFarad, 250VAC Motor Run
4 807-2572 Microswitch
5 Resistor Assembly
806-8530SP 100-120V Modular Basket Lift (see Note 2 in illustration)
106-2771 208-250V Modular Basket Lift (before 11/02 use 806-9185 ; see illust. Note 3 )
6 809-0082 Ring, Truarc Retaining
7 826-1361 Screw, 2-32 X 1-inch Slotted Truss Head (Pkg. of 25)
8 809-0127 Screw, ¼-20 X ½-inch Slotted Round Head
9 809-0186 Lock Washer w/External Teeth, #8
10 826-1366 Nut, 4-40 Hex Keps (Pkg. of 25)
11 809-0247 Nut, 2-32 Hex Keps
12 826-1359 Screw, 4-40 X ¾-inch Slotted Round Head (Pkg. of 25)
13 826-1371 Screw, #8 X ½-inch Hex Head Drill Point (Pkg. of 25)
14 826-1374 Screw, #10 X ½-inch Hex Head (Pkg. of 25)
15 809-0503 Screw, 2-32 X ½-inch Hex Head
16 810-0172 Plug, 5 ⁄
8-
inch Stainless Steel Hole
17 810-1012 Rod, Modular Basket Lift
18 812-0442 Insulation, Microswitch
19 813-0035 Bushing, Bronze, .640” ID
20 816-0033 Tie Wrap, Screw Mount
21 900-5529 Gusset, Modular Basket Lift Motor
22 901-8499 Chassis, Modular Basket Lift, Left
23 902-8499 Chassis, Modular Basket Lift, Right
24 910-4776 Cover, S/S Modular Basket Lift (for CRS cover use 900-4776)
25 823-06931 Arm, Left Basket Lift
26 823-06932 Arm, Right Basket Lift
Basket Lift Assemblies (see Note 1 in illustration)
* 106-1807SP 100-120V w/o Relay
* 106-1810SP 208-250V w/o Relay
** * Not illustrated.
* ** Basket lift assemblies manufactured prior to February 2002 have 6-pin connectors; those manufactured
February 2002 and later have 12-pin connectors. Verify the connector in use before ordering wiring
assemblies or mounts.
*** To replace stripped drive gear only, order 810-1013 (gear), 810-0973 (Woodruff key) and 809-0504
(setscrew).
NOTE: See Page 2-20 for Roller Bracket Assembly.
