Modular basket lift simplified wiring diagram – Frymaster 45 Series User Manual
Page 33
1-27
Modular Basket Lift Simplified Wiring Diagram
NOTE: References to right and left are from the rear of the fryer.
BL
U
E
ORA
N
G
E
RED
WH
IT
E
G
R
EEN
BL
AC
K
BRN 1
RED 1
BLK
BRN 2
RED 2
UPPER
SWITCH
UPPER
SWITCH
LOWER
SWITCH
LOWER
SWITCH
BLK
LEFT SIDE
RIGHT SIDE
12.5
μ F
12.5
μ F
12.5
μ F
RESISTORS
(either 2 or 6
depending on
voltage and
date of
manufacture)
